UNICLEAN SL L 170

‹ ›

Product images are for illustrative purposes only and may differ from the actual product.

Chamber volume
- 170 litres
Basket volume
- 150 litres
Basic features
- stable, resistant stainless steel structure of the device and its outer shell of steel (AISI 304) is characterised by long service life
- 20 standard washing and disinfection programs and 20 others according to client´s specification
- manually controlled hinged chamber door of steel
- built-in steam condenser
- two up to three dosing pumps

UNICLEAN SL L 170 is designed specifically for installation in limited space as a stand-alone device with front filling, suitable for placement under the desk plate. Simple installation with necessity of electric connection, cold water and sewerage connection can be used mainly in small private practices for thermal disinfection and washing of laboratory glass. After closing the manually open hinged door, the washing process is automatically performed. This small model includes built-in washing and air drying on two levels generally used at large devices. The device is ideal for reduction and elimination of professional risk caused by handling the infectious material.

I am interested in UNICLEAN SL L 170

General Information

Characteristics

small inner dimensions
washing and drying on two levels
built-in steam condenser
integrated water softener
two up to three dosing pumps
output for external printer

Programs, documentation of batches

20 standard washing and disinfection programs and 20 others according to client´s specification
direct selection of the most frequently selected programs on the control panel:
P1 - short cycle, suitable for slightly polluted objects
P2 - standard cycle, suitable for generally polluted objects
P3 - intensive cycle, suitable for highly polluted objects
access to other pre-set program via the button P+
programs developed specially for various type of treated products, types of pollution or types of washing (bottles, blood, microbiological, oils and petrol, thermo chemical disinfection, enzymatic cleaning)
two short pre-set programs for simple rinsing of treated products with cold water or for drying of already washed objects
batches documentation – connection to printer or PC (RS 232) or to computer network (LAN) together with software application Ecosoft

Structure

stable, resistant stainless steel structure of the device and its outer shell of steel (AISI 304) is characterised by long service life
chamber, washing arms and filter tanks of high-quality steel (AISI 316L)
manually controlled hinged chamber door of steel
inclined chamber bottom avoids water accumulation in the chamber and it speeds up drainage and drying
rounded corners and edges of the chamber make washing easier and they avoid impurities sticking

Control panel

built-in control systems – management and control of all the programs of the device and their phases
ergonomic control panel built in the device jacket, with black and white two line LCD display, it shows the program phases, current date and time, control temperature and regulation temperature, required temperature of the phase, value Ao – control and regulation, remaining time of the cycle and possible error messages of the device
Start and Stop push buttons on the main panel of the device
Drying push button for drying phase omission in standard selected cycle
every pressing of the control panel is indicated by a sound signal
current status of the device is indicated by eight functional LED diodes on the control panel
access to the cycle parameters is protected by a password according to ISO 15883-1/2

Use

Optional Equipment

Hot air drying, 98% DOP filter – integrated drying guarantees perfectly dry products in the end of the washing cycle
Language version (display) – other than English - standard languages of control are: English, German, Spanish
Instructions for use: other than English (if available)
Instructions for servise: other than English (if available)
Tank for DI (demi) water pre-heating – reduction of total time of the program by shortening the time needed for water heating in the chamber
Another dosing pump – in case of using more chemicals it is possible to extend the standard configuration
Auxiliary pump for DI (demineralised) water
HEPA filter of air H14 (spare part) – guarantee of safe device servicing
Stainless steel basement 600×560×600H mm - comfortable ergonomic device servicing
Two-level case for detergents made of stainless steel 300×630×840H mm - comfortable ergonomic device servicing
Thermo printer for process documentation (for Uniclean SL L 170 external) – comfortable and well organised way of washed batch revision
Complementary stainless steel lining (price per 1 m2)
Water softener – arrangement of required quality and economic operation and installation problems solving
10 l plastic vessel for resin 500h mm with basic and overpressure valve and conductibility system
25 l resin
Water cleaning system: reversal osmosis – arrangement of required quality and economic operation and installation problems solving
Packaging in plywood box
Washer extension to 900 mm in integrated case for detergents and options
Stainless steel basement 900×560×600H mm for extended washer to 900 mm
Increased heating performance 8000 W - shortening of time needed for washing water pre-heating
Glass door - for better washing process monitoring
Remote administration software – simple displaying of operation cycles, easy administration of configured devices at CSSD
Bar code reader – the appropriate washing program is selected after bar code scanning
